Refuelling equipment

Universal refuelling steps for all aircraft types and fast, safe and easy refuelling at wind speeds up to 8 Beaufort.

Refuelling equipment with nozzles/couplings, hoses, earthing device and connectors available as optional equipment.


Refuelling ladder

Aluminium ladders with fixed height – mobile, stable and secure when in use. Single or two-sided access.

  • Platform height: 0.78/… /1.58 m.
  • Working height: 2.00 to 3.60 m.
  • Main aircraft type: regional jets.
  • Permissible load capacity: 150 kg.
  • Large working platform 400 x 400 mm for safe standing.
  • Tray for aircraft fuel cap.
  • Nozzle rest on side-piece.
  • Double-sided foldable handrails with heat-shrink hose.
  • Single-sided access.
  • Optional 3 to 6 steps.

Single axle fixed-height refuelling steps

Lower section of the steps can be folded to enable improved manoeuvrability when transporting.

  • Platform height: 1.50 m.
  • Working height: 2.90 m to 3.40 m.
  • Main aircraft types: regional jets, narrow-body.
  • Platform dimensions: 500 × 800 mm.
  • Overall dimensions: 3,210 × 1,670 × 2,500 mm
  • Floor: safety panels, antiskid and pervious to water.
  • Guardrail height 1,000 mm.
  • Pneumatic tyres with ∅ 400 mm and towbar for max. 30m/h.
  • 1-axle.

Two axle fixed-height refuelling steps

Refuelling can be performed from every step.

  • Platform height: 1.60 m.
  • Working height: 2.90 to 3.50 m.
  • Main aircraft types: Narrow-body aircraft.
  • Platform dimensions: 600 × 400 mm.
  • Overall dimensions: 2,930 × 1,610 × 2,600 mm
  • Floor: Safety panels, anti-slip and pervious to water.
  • Guardrail height 1,000 mm.
  • Pneumatic tyres with ∅ 450 mm and towbar for max. 30 km/h.
  • Standard refuelling equipment included: container, storage tray, pressure relief and spring balance for for lightweight handling of the nozzle.
  • 2-axle.

Two axle height adjustable refuelling steps – small and large

Based on a hydraulic hub system. Optionally available with single or dual sided refuelling unit.

  • Small platform height/working height: 1.93 to 3.25 m/3.50 to 5.20 m.
  • Large platform height/working height: 2.49 to 4.25 m/4.00 to 6.20 m.
  • Main aircraft types: Widebody aircraft.
  • Platform dimensions: 940 × 830 mm.
  • Overall dimensions for 3-550-325: 5,700 × 2,200 × 3,300 mm
  • Base: Safety panels, anti-slip and pervious to water.
  • Guardrail height 1,100 mm.
  • Pneumatic tyres with ∅ 530 mm and towbar for max. 30 km/h.
  • Standard refuelling equipment included: container, storage tray, pressure relief and spring balance.
